SPECIFICATION
| Model No. | B12 | Color | White & Customizable |
| Electric System | |||
| Motor | Bafang 48V500W rear wheel hub motor | Battery | 48V 12.5Ah lithium battery |
| Controller | Intelligent controller | Display | LCD Display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | Thumb Throttle |
| Charger | 2A, 110-240V applied | ||
| Main Components | |||
| Frame | Alu alloy | Fork | MOZO,FATMAN 26inch alloy |
| Handlebar | Promax HB-3018,22.2*31.8*W700mm | Stem | Promax MA-400 |
| Brake | F&R Tektro mechanical disc brake | Brake Lever | Alu alloy |
| Tyre | Kenda 26”*4.0 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Head Light, Rear light |
| Chainwheel | Prowheel 46T with plastic cover | Crank | Prowheel, 170mm |
| Chain | KMC Z7 | Gear | Shimano 7-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | Velo VL-3125 | Grip | HL, rubber black |
| Pedal | YH,black with reflector | Rack | Front Basket and Rear Rack |
| Performance | |||
| Range | 31-60km | Charging Time | 3-6h |
| Max. Load | 120kg | Max. Speed | 50km/h |
| Warranty | 1 year for the whole piece |
Front Basket
We set a front basket on this fat tire bike,It offers great convenience as you can put your backpack, bags, etc. in the basket and free up your own space.
Prowheel Chainwheel
To achieve a better transmission, we have fitted this fat ebike with Prowheel chainwheel and crank,to give you a comfortable drive when pedalling.
Shimano 7 Speed Gear
Shimano Acera 7-spd allows for fast and smooth shifting, making it possible to adjust the gears for shifting smoothly at any time during your ride. Offering a comfortable ride for you.
