SPECIFICATION
| Model No. | B23 | Color | Black & Customizable |
| Electric System | |||
| Motor | 48V500W Rear integrated wheel motor | Battery | 48V 10Ah lithium battery |
| Controller | Intelligent controller | Display | KT LCD Display |
| PAS Sensor | 12 magnet cadence sensor | Throttle | Thumb Throttle |
| Charger | 2A, 110-240V applied | ||
| Main Components | |||
| Frame | Alu alloy | Fork | MOZO 20inch snow fat sus fork |
| Handlebar | Promax HB-T303,W620*22.2*2.6T | Stem | FH-03W foldable and adjustable |
| Brake | F&R Tektro hydraulic disc brake | Brake Lever | Alu alloy |
| Tyre | Kenda 20”*4.0 | Rim | Double Wall Rim |
| Spoke | Stainless Steel | Light | Head Light, Rear light |
| Chainwheel | Prowheel 52T with plastic cover | Crank | Prowheel, Alu alloy 170mm |
| Chain | KMC Z7, Steel | Gear | Shimano 7-spd |
| Shift Lever | Thumb Type | Kickstand | Alu alloy/ Steel |
| Saddle | Justek 5693DSN foldable type | Grip | HL,125mm length,black |
| Pedal | Black Comfortable Pedal | Rack | No |
| Performance | |||
| Range | 31-60km | Charging Time | 3-6h |
| Max. Load | 120kg | Max. Speed | 50km/h |
| Warranty | 1 year for the whole piece |
KT LCD Display
The clear display shows all the necessary information,riding speed, single mileage and accumulated mileage…It also has cruise control function, intelligent power display function here you can also select your individiual support.
F&R integrated wheel motor
It is paired with integrated wheel motor,the tyre cushioning pressure and comparative shock resistance are excellent,less fatigue,and the handlebars can be freely extended even on steep hills.
Tektro Hydraulic Disc Brake
This model uses hydraulic disc brakes. Its handlebars are very gentle, which means that when we ride with hydraulic disc brakes we only need to use a small amount of force to get a lot of braking power.
